Trigger settings (cf. Tab. B.1.41, Tab.B.1.42).
Vector measurement settings - cf. Tab. B.1.6.
FFT analysis header - cf. Tab.B.1.8.
Settings for vibration dose measurement (the presence depends on the MEASURE DOSE and channel filter
settings) - cf. Tab. B.1.9.
Main results - cf. Tab. B.1.10.
RPM results (present if RPM measurement was enabled) - cf. Tab. B.1.34.
SEAT measurements settings (cf. Tab. B.1.36).
Selected statistical levels in channels - cf. Tab. B.1.11.
One-channel FFT analysis results (one for each channel with spectrum analysis enabled) -
cf. Tab.B.1.13.
Header of the statistical analysis in channels (the presence depends on the SAVE STAT. setting) - cf. Tab.
B.1.18.
Results of the statistical analysis in one channel (the presence depends on the SAVE STAT. setting) - cf. Tab.
B.1.19.
Sound Intensity analysis results - cf. Tab. B.1.45
File end marker - cf. Tab. B.1.25.
B.16. CONTENTS OF THE FILE IN THE LOGGER
The records with the results and the records with the state of the markers as well as the records
with the breaks in the results registration are saved in the files in the logger.
B.16.1. Record with the results
The contents of the record with the results depends on the measurement function, selected channels modes,
values set in the LOGGER SETUP menu and its sub-lists, channels selected for spectrum analysis and values
set in the LOGGER MODE (path: MENU / INPUT / 1/1 OCTAVE or 1/3 OCTAVE or FFT SETUP / CHANNEL x
/ LOGGER:RMS). All results are written in dB*10. Profile results are written on 15 most significant bits, while
least significant bit is used for overload indication flag. The following elements can be present (in the given
sequence):
• results of the measurement from the 1
st
profile of the 1
st
channel if the LOGGER list was marked and
LOGGER MODE was set to ON (path: MENU / INPUT / LOGGER SETUP / LOGGER MODE:ON) and
if any position in CHAN. 1 PROF. 1 (path: MENU / INPUT / LOGGER SETUP / CHANNEL 1 /
CHAN. 1 PROF. 1) sub-list was selected, up to five words are written in the given sequence:
<result1> - PEAK result in the case of VLM or in the case of SLM if the first position was marked,
else no value is written;
<result2> - P–P result in the case of VLM or MAX result in the case of SLM if the second position was
marked, else no value is written;
<result3> - MAX result in the case of VLM or MIN result in the case of SLM if the third position was marked,
else no value is written;
<result4> - RMS result in the case of VLM or in the case of SLM if the fourth position was marked, else no
value is written;
<result5> - VDV result in the case of VLM if the fifth position was marked, else no value is written;
• results of the measurement from the 1
st
profile of the 2
nd
channel if the LOGGER MODE was set to ON
(path: MENU / INPUT / LOGGER SETUP / LOGGER MODE:ON); and if any position in CHAN. 2
