SVAN 958A User Manual
Function for Digital In AC/Int. mode
XP
XP0 - trigger pulse
Function for Digital Out AC/Int.
mode
XQ
XQ0 - trigger pulse
XQ1 - alarm pulse
AC/Int. polarization
XU
XU0 - positive
XU1 - negative
AC/Int. active level
XV
XV0 - active low
XV1 - active high
Vector alarm mode
Xc
Xc0:0 - OFF
Xc1:0 - LEVEL -
Xc2:0 - LEVEL +
Xc3:0 - SLOPE -
Xc4:0 - SLOPE +
Xc5:0 - GRADIENT -
Xc6:0 - GRADIENT +
Vector alarm step
Xe
Xe0:0 - logger step
Xe1:0 - 100 ms
Xe2:0 - 1 s
Xe3:0 - current
Xe4:0 - integration period
Vector alarm level
Xf
Xfnnn:0 - nnn alarm level in dB*10
Profile alarm mode for VLM
Xi
Xi0:P:K - OFF
Xi1:P:K - LEVEL -
Xi2:P:K - LEVEL +
Xi3:P:K - SLOPE -
Xi4:P:K - SLOPE +
Xi5:P:K - GRADIENT -
Xi6:P:K - GRADIENT +
P - profile number
K - number of alarm in profile
Profile alarm mode for SLM
Xj
Xj0:P:K - OFF
Xj1:P:K - LEVEL -
Xj2:P:K - LEVEL +
Xj3:P:K - SLOPE -
Xj4:P:K - SLOPE +
Xj5:P:K - GRADIENT -
Xj6:P:K - GRADIENT +
P - profile number
K - number of alarm in profile
