Preamplifier
SV 12L nominal preamplifier attenuation: 0.7 dB;
IEPE Type – power supply 1.5 mA@30 V
SV12L typical frequency response
Effect of the SC26 extension cable of 3- and 10-meters length
Effect of extension cable for measurement filter LIN for Uin=1 V
RMS
Note: Using of the extension cable has no effect on the linearity operation ranges.
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
A [dB]
f [Hz]
with preamplifier SC26 3m SC26 10m
