Dytran 3143M1
Physical
Weight 4 Grams
Size, Dia x Height 1.24 X 0.91 X 0.91 cm
Mounting M3x0.5 TAPPED HOLE IN BASE
Connector 4-PIN
Material, housing & connector Titanium Alloy
Performance
Sensitivity, -10 +15% [1] 1.2 mV/ms-2
Range F.S. ± 500 G
Frequency response -5 / +15%, 1.5 to 10 000 Hz
Natural frequency, mounted Nom. 40 kHz
Linearity 1% FS
Transverse sensitivity MAX. 5 %
Environmental
Maximum vibration/shock 600/ 5000 G
Temperature range -50 to +120 oC
Seal HERMETIC
Coefficient of thermal sensitivity 0.054 %/ °C
Electrical
Supply current/compliance voltage range 2 to 20/+18 to +30 mA/Volts
Output impedance typ. 100 Ohms
Output bias voltage +10 VDC
Ground isolation CASE GROUNDED
