SVAN 958A User Manual
Table C.8.10. Self-generated noise for different weighting filters
Electrical *)
Acoustical compensated
Weighting filter
Range
A
C
LIN
A
C
LIN
Low
< 15 dB
< 15 dB
< 21 dB
< 19 dB
< 19 dB
< 25 dB
High
< 35 dB
< 35 dB
< 37 dB
< 39 dB
< 39 dB
< 41 dB
*) measured with the ST 02 microphone equivalent impedance 18 pF +/-10%
Free Field Frequency response of SVAN 958A with SA 277C for 0 deg incidence angle
