Note: When the HAV/WBV dosimeter is enabled the D letter appears before the function
abbreviations (e.g. DLM, D1/1, DDos etc.)
If filters of different type of integration are selected (for example HP and Vel),
the “Vibration Dosimeter Off - Incorrect Dosimeter Settings” message
appears on the display and the vibration dosimeter is switched off
automatically.
Commonly used filters for measurements of:
Hand-Arm vibration dose:
➢ Wh for X axis
➢ Wh for Y axis
➢ Wh for Z axis
Whole-Body vibration dose:
➢ Wd for X axis
➢ Wd for Y axis
➢ Wk for Z axis.
The Exposure Time enables the user to set the desired value of the exposure
time that is used for the calculation of HAV/WBV Dose results. The
Exposure Time values are within the range [00h01, 24h00].
The Standards position enables the user to set the standards for the
measurements of the HAV/WBV Dose results. The available values of this
position are U.K., Italy, Poland, France and User.
The X Axis, Y Axis, Z Axis positions enable setting of proper channels to be
taken for calculation of the HAV/WBW Dose results.
The View Standatd Limits position enables
the user to see what are the limits used by
selected country standard.
In case the User option it is possible to define
the required limits.
