EC140E L without dozer
blade
H
1.5 m 3.0 m 4.5 m 6.0 m 7.5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Variable adjustable boom:
4.6 m
Dipper arm: 2.1 m
Shoe: 600 mm
Counterweight: 2450 kg
7.5 m - - - - - - - - - - *5580 *5580 2.90
6 m - - *5070 *5070 *4800 4170 - - - - *3980 3470 5.01
4.5 m - - *5470 *5470 *4950 4120 3980 2600 - - *3580 2540 6.07
3 m - - - - *5740 3930 3930 2560 - - 3350 2180 6.62
1.5 m - - - - 5930 3700 3830 2470 - - 3170 2050 6.80
0 m - - - - 5760 3550 3750 2400 - - 3260 2100 6.62
-1.5 m - - *9290 6440 5720 3520 3750 2400 - - 3680 2360 6.08
Variable adjustable boom:
4.6 m
Dipper arm: 2.5 m
Shoe: 600 mm
Counterweight: 2450 kg
7.5 m - - *5180 *5180 - - - - - - *4160 *4160 3.75
6 m - - *4390 *4390 *4320 4250 - - - - *3210 2990 5.54
4.5 m - - *4120 *4120 *4560 4170 4020 2640 - - *2930 2290 6.51
3 m - - - - *5390 3970 3940 2570 - - *2870 1990 7.02
1.5 m - - - - 5960 3720 3830 2470 - - 2910 1880 7.19
0 m - - - - 5760 3550 3740 2380 - - 2980 1920 7.02
-1.5 m - - *9130 6380 5680 3480 3700 2350 - - 3310 2120 6.51
-3 m - - - - *5410 3520 - - - - - - 5.54
Variable adjustable boom:
4.6 m
Dipper arm: 3.0 m
Shoe: 600 mm
Counterweight: 2450 kg
7.5 m - - *4120 *4120 *3610 *3610 - - - - *3250 *3250 4.64
6 m - - - - *3750 *3750 *3160 2660 - - *2660 2530 6.16
4.5 m - - *3000 *3000 *3780 *3780 *3850 2670 - - *2450 2010 7.05
3 m - - - - *4890 4020 3960 2580 *2550 1790 *2400 1770 7.52
1.5 m - - - - *5980 3740 3830 2460 2720 1750 *2470 1680 7.68
0 m - - - - 5750 3530 3710 2350 2680 1710 *2660 1700 7.53
-1.5 m *3630 *3630 *8260 6270 5630 3420 3650 2300 - - 2910 1850 7.05
-3 m - - *8660 6330 5630 3430 3680 2330 - - 3550 2250 6.17
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
