Volvo EC140E - Page 405

For Europe
EC140E L without dozer
blade
H
1.5 m 3.0 m 4.5 m 6.0 m 7.5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Boom: 4.6 m
Dipper arm: 2.1 m
Shoe: 600 mm
Counterweight: 2450 kg
6 m - - - - *3320 *3320 - - - - *3500 *3500 4.90
4.5 m - - - - *3470 *3470 - - - - *3570 2610 5.98
3 m - - *6230 *6230 *4330 3910 *3750 2550 - - 3400 2230 6.54
1.5 m - - - - *5390 3700 3800 2470 - - 3220 2100 6.71
0 m - - *5400 *5400 5730 3560 3730 2410 - - 3300 2140 6.54
-1.5 m *5010 *5010 *9440 6460 5690 3520 - - - - 3740 2410 5.98
-3 m - - *8220 6580 *5470 3590 - - - - *4820 3200 4.91
Boom: 4.6 m
Dipper arm: 2.5 m
Shoe: 600 mm
Counterweight: 2450 kg
6 m - - - - *2840 *2840 - - - - *3210 3100 5.41
4.5 m - - - - *3080 *3080 *3190 2630 - - *3170 2350 6.40
3 m - - *5330 *5330 *3950 3950 *3490 2560 - - 3110 2040 6.93
1.5 m - - - - *5070 3720 3810 2470 - - 2960 1930 7.09
0 m - - *5970 *5970 5730 3550 3720 2390 - - 3020 1960 6.93
-1.5 m *4550 *4550 *9610 6390 5650 3490 3690 2360 - - 3360 2170 6.41
-3 m *8940 *8940 *8690 6480 5700 3520 - - - - 4320 2750 5.42
Boom: 4.6 m
Dipper arm: 3.0 m
Shoe: 600 mm
Counterweight: 2450 kg
7.5 m - - - - - - - - - - *2870 *2870 4.47
6 m - - - - - - *2860 2650 - - *2810 2620 6.04
4.5 m - - - - - - *2780 2650 - - *2640 2070 6.94
3 m - - - - *3440 *3440 *3140 2570 - - *2630 1820 7.42
1.5 m - - *7320 6830 *4620 3730 *3680 2460 2700 1750 2660 1720 7.58
0 m - - *6510 6400 *5620 3530 3690 2360 - - 2700 1740 7.42
-1.5 m *3990 *3990 *8760 6290 5600 3430 3630 2310 - - 2960 1900 6.94
-3 m *7370 *7370 *9080 6340 5600 3430 3660 2330 - - 3620 2310 6.04
-4.5 m - - *7210 6540 - - - - - - *4480 3590 4.48
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
Specifications
Lifting capacities 403
