EC140E L without dozer
blade
1.5 m 3.0 m 4.5 m 6.0 m 7.5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Variable adjustable boom:
4.6 m
Dipper arm: 2.1 m
Shoe: 700 mm
Counterweight: 2450 kg
7.5 m - - - - - - - - - - *5580 *5580 2.90
6 m - - *5070 *5070 *4800 4240 - - - - *3980 3520 5.01
4.5 m - - *5470 *5470 *4950 4190 4050 2650 - - *3580 2590 6.07
3 m - - - - *5740 3990 4000 2600 - - 3410 2220 6.62
1.5 m - - - - 6040 3760 3900 2510 - - 3230 2090 6.80
0 m - - - - 5870 3620 3830 2440 - - 3320 2140 6.62
-1.5 m - - *9290 6560 5830 3580 3820 2440 - - 3750 2400 6.08
Variable adjustable boom:
4.6 m
Dipper arm: 2.5 m
Shoe: 700 mm
Counterweight: 2450 kg
7.5 m - - *5180 *5180 - - - - - - *4160 *4160 3.75
6 m - - *4390 *4390 *4320 4310 - - - - *3210 3040 5.54
4.5 m - - *4120 *4120 *4560 4240 4090 2690 - - *2930 2330 6.51
3 m - - - - *5390 4030 4020 2620 - - *2870 2030 7.02
1.5 m - - - - 6070 3790 3900 2510 - - *2970 1920 7.19
0 m - - - - 5870 3610 3810 2430 - - 3040 1950 7.02
-1.5 m - - *9130 6490 5790 3540 3780 2400 - - 3370 2160 6.51
-3 m - - - - *5410 3580 - - - - - - 5.54
Variable adjustable boom:
4.6 m
Dipper arm: 3.0 m
Shoe: 700 mm
Counterweight: 2450 kg
7.5 m - - *4120 *4120 *3610 *3610 - - - - *3250 *3250 4.64
6 m - - - - *3750 *3750 *3160 2710 - - *2660 2570 6.16
4.5 m - - *3000 *3000 *3780 *3780 *3850 2710 - - *2450 2050 7.05
3 m - - - - *4890 4080 4030 2620 *2550 1820 *2400 1810 7.52
1.5 m - - - - *5980 3810 3900 2500 2770 1780 *2470 1710 7.68
0 m - - - - 5850 3590 3780 2400 2730 1740 *2660 1730 7.53
-1.5 m *3630 *3630 *8260 6390 5730 3490 3720 2340 - - 2970 1890 7.05
-3 m - - *8660 6440 5740 3490 3750 2370 - - *3580 2290 6.17
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
