Volvo EC140E - Page 409

EC140E L without dozer
blade
H
1.5 m 3.0 m 4.5 m 6.0 m 7.5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Boom: 4.6 m
Dipper arm: 2.1 m
Shoe: 700 mm
Counterweight: 2100 kg
6 m - - - - *3320 *3320 - - - - *3500 3450 4.90
4.5 m - - - - *3470 *3470 - - - - *3570 2490 5.98
3 m - - *6230 *6230 *4330 3750 *3750 2440 - - 3280 2130 6.54
1.5 m - - - - *5390 3530 3670 2360 - - 3100 2000 6.71
0 m - - *5400 *5400 5540 3400 3600 2290 - - 3180 2040 6.54
-1.5 m *5010 *5010 *9440 6160 5490 3360 - - - - 3610 2290 5.98
-3 m - - *8220 6280 *5470 3430 - - - - *4820 3050 4.91
Boom: 4.6 m
Dipper arm: 2.5 m
Shoe: 700 mm
Counterweight: 2100 kg
6 m - - - - *2840 *2840 - - - - *3210 2970 5.41
4.5 m - - - - *3080 *3080 *3190 2520 - - *3170 2250 6.40
3 m - - *5330 *5330 *3950 3780 *3490 2450 - - 3010 1950 6.93
1.5 m - - - - *5070 3550 3680 2350 - - 2850 1830 7.09
0 m - - *5970 *5970 5530 3390 3590 2280 - - 2910 1860 6.93
-1.5 m *4550 *4550 *9610 6100 5460 3320 3560 2250 - - 3240 2060 6.41
-3 m *8940 *8940 *8690 6190 5500 3360 - - - - 4170 2620 5.42
Boom: 4.6 m
Dipper arm: 3.0 m
Shoe: 700 mm
Counterweight: 2100 kg
7.5 m - - - - - - - - - - *2870 *2870 4.47
6 m - - - - - - *2860 2530 - - *2810 2500 6.04
4.5 m - - - - - - *2780 2540 - - *2640 1970 6.94
3 m - - - - *3440 *3440 *3140 2450 - - *2630 1730 7.42
1.5 m - - *7320 6530 *4620 3570 3670 2340 2610 1660 2560 1630 7.58
0 m - - *6510 6100 5510 3360 3560 2240 - - 2600 1650 7.42
-1.5 m *3990 *3990 *8760 6000 5400 3270 3500 2190 - - 2850 1800 6.94
-3 m *7370 *7370 *9080 6050 5400 3270 3530 2210 - - 3490 2190 6.04
-4.5 m - - *7210 6250 - - - - - - *4480 3430 4.48
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
Specifications
Lifting capacities 407
