Volvo EC140E - Page 410

EC140E L with dozer
blade
H
1.5 m 3.0 m 4.5 m 6.0 m 7.5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Boom: 4.6 m
Dipper arm: 2.1 m
Shoe: 500 mm
Counterweight: 2450 kg
Dozer blade: Down
6 m - - - - *3320 *3320 - - - - *3500 *3500 4.90
4.5 m - - - - *3470 *3470 - - - - *3570 2920 5.98
3 m - - *6230 *6230 *4330 *4330 *3750 2860 - - *3710 2500 6.54
1.5 m - - - - *5390 4160 *4170 2770 - - *3910 2360 6.71
0 m - - *5400 *5400 *6100 4020 *4520 2710 - - *4160 2410 6.54
-1.5 m *5010 *5010 *9440 7380 *6220 3980 - - - - *4470 2710 5.98
-3 m - - *8220 7500 *5470 4050 - - - - *4820 3600 4.91
Boom: 4.6 m
Dipper arm: 2.5 m
Shoe: 500 mm
Counterweight: 2450 kg
Dozer blade: Down
6 m - - - - *2840 *2840 - - - - *3210 *3210 5.41
4.5 m - - - - *3080 *3080 *3190 2930 - - *3170 2630 6.40
3 m - - *5330 *5330 *3950 *3950 *3490 2870 - - *3160 2290 6.93
1.5 m - - - - *5070 4180 *3970 2770 - - *3340 2170 7.09
0 m - - *5970 *5970 *5920 4010 *4400 2690 - - *3740 2210 6.93
-1.5 m *4550 *4550 *9610 7310 *6220 3950 *4520 2660 - - *4150 2440 6.41
-3 m *8940 *8940 *8690 7400 *5770 3980 - - - - *4510 3100 5.42
Boom: 4.6 m
Dipper arm: 3.0 m
Shoe: 500 mm
Counterweight: 2450 kg
Dozer blade: Down
7.5 m - - - - - - - - - - *2870 *2870 4.47
6 m - - - - - - *2860 *2860 - - *2810 *2810 6.04
4.5 m - - - - - - *2780 *2780 - - *2640 2320 6.94
3 m - - - - *3440 *3440 *3140 2870 - - *2630 2050 7.42
1.5 m - - *7320 *7320 *4620 4200 *3680 2760 *3110 1980 *2760 1940 7.58
0 m - - *6510 *6510 *5620 3990 *4190 2660 - - *3040 1970 7.42
-1.5 m *3990 *3990 *8760 7210 *6110 3890 *4460 2610 - - *3590 2140 6.94
-3 m *7370 *7370 *9080 7260 *5950 3890 *4160 2630 - - *4100 2610 6.04
-4.5 m - - *7210 *7210 - - - - - - *4480 4050 4.48
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
