Volvo EC140E - Page 413

EC140E LM
H
1.5 m 3.0 m 4.5 m 6.0 m 7.5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Boom: 4.6 m
Dipper arm: 2.1 m
Shoe: 700 mm
Counterweight: 2450 kg
6 m - - - - *3280 *3280 - - - - *3500 *3500 5.08
4.5 m - - - - *3550 *3550 *3560 2840 - - *3580 2780 6.07
3 m - - *6660 *6660 *4470 4230 *3800 2780 - - 3630 2420 6.58
1.5 m - - - - *5510 4020 4100 2700 - - 3470 2300 6.71
0 m - - *5920 *5920 *6150 3890 4030 2640 - - 3610 2380 6.49
-1.5 m *5680 *5680 *9340 7080 6130 3870 - - - - 4150 2710 5.88
-3 m - - *7960 7210 *5240 3960 - - - - *4870 3720 4.71
Boom: 4.6 m
Dipper arm: 2.5 m
Shoe: 700 mm
Counterweight: 2450 kg
6 m - - - - *2820 *2820 - - - - *3220 *3220 5.57
4.5 m - - - - *3160 *3160 *3210 2860 - - *3160 2520 6.49
3 m - - *5740 *5740 *4090 *4090 *3540 2790 - - *3180 2220 6.97
1.5 m - - - - *5210 4030 *4040 2700 - - 3200 2120 7.09
0 m - - *6280 *6280 *5990 3880 4010 2620 - - 3300 2180 6.88
-1.5 m *5050 *5050 *9550 7010 6090 3830 3990 2600 - - 3720 2440 6.31
-3 m *9660 *9660 *8480 7110 *5630 3880 - - - - *4550 3160 5.25
Boom: 4.6 m
Dipper arm: 3.0 m
Shoe: 700 mm
Counterweight: 2450 kg
7.5 m - - - - - - - - - - *2860 *2860 4.73
6 m - - - - - - *2800 *2800 - - *2780 2750 6.18
4.5 m - - - - - - *2810 *2810 - - *2630 2220 7.02
3 m - - *4600 *4600 *3580 *3580 *3200 2790 - - *2640 1980 7.46
1.5 m - - *7660 7360 *4770 4050 *3750 2680 2930 1930 *2780 1900 7.57
0 m - - *6630 *6630 *5710 3850 3980 2590 - - 2960 1940 7.38
-1.5 m *4370 *4370 *9250 6900 6030 3770 3930 2540 - - 3270 2130 6.85
-3 m *7910 *7910 *8930 6970 *5870 3790 - - - - 4070 2640 5.89
-4.5 m - - *6780 *6780 - - - - - - - - 4.20
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
Specifications
Lifting capacities 411
