EC140E LM
1.5 m 3.0 m 4.5 m 6.0 m 7.5 m Max. Reach
Max.
kg kg kg kg kg kg kg kg kg kg kg kg m
Variable adjustable boom:
4.6 m
Dipper arm: 2.1 m
Shoe: 700 mm
Counterweight: 2450 kg
7.5 m - - *5890 *5890 - - - - - - *5170 *5170 3.30
6 m - - *5090 *5090 *4760 4530 - - - - *3900 3570 5.19
4.5 m - - *5740 *5740 *5020 4450 4280 2840 - - *3560 2710 6.17
3 m - - - - *5860 4240 4210 2790 - - *3510 2360 6.67
1.5 m - - - - 6340 4020 4120 2700 - - 3430 2260 6.79
0 m - - - - 6190 3890 4050 2630 - - 3560 2330 6.58
-1.5 m - - *9070 7060 6160 3860 - - - - 4080 2660 5.97
Variable adjustable boom:
4.6 m
Dipper arm: 2.5 m
Shoe: 700 mm
Counterweight: 2450 kg
7.5 m - - *4960 *4960 - - - - - - *3950 *3950 4.06
6 m - - *4290 *4290 *4310 *4310 - - - - *3160 3110 5.69
4.5 m - - *4220 *4220 *4640 4500 *4240 2880 - - *2910 2450 6.6
3 m - - - - *5520 4280 4230 2800 - - *2880 2170 7.06
1.5 m - - - - 6370 4040 4120 2700 - - *2990 2070 7.18
0 m - - *5730 *5730 6180 3880 4030 2620 - - 3250 2130 6.98
-1.5 m - - *9640 6990 6120 3820 4010 2590 - - 3660 2380 6.41
-3 m - - - - - - - - - - - - 5.54
Variable adjustable boom:
4.6 m
Dipper arm: 3.0 m
Shoe: 700 mm
Counterweight: 2450 kg
7.5 m - - - - *3860 *3860 - - - - *3120 *3120 4.9
6 m - - - - *3750 *3750 *3380 2910 - - *2620 *2620 6.31
4.5 m - - *3010 *3010 *3820 *3820 *3870 2900 - - *2430 2160 7.13
3 m - - - - *5050 4330 *4230 2800 *2730 1970 *2400 1940 7.56
1.5 m - - - - *6100 4050 4110 2680 2940 1930 *2480 1860 7.68
0 m - - *6050 *6050 6160 3850 4000 2580 - - *2700 1900 7.48
-1.5 m *4020 *4020 *8770 6880 6060 3760 3950 2540 - - *3140 2090 6.96
-3 m - - *8350 6960 *5710 3780 - - - - - - 6.02
: Along undercarriage, : Across undercarriage, H : Lifting hook related to ground
level
1. Machine in "Fine Mode-F" (Power Boost), for lifting capacities.
2. The above loads are in compliance with SAE and ISO Hydraulic Excavator Lift Capacity
Standards.
3. Rated loads do not exceed 87% of hydraulic lifting capacity or 75% of tipping load.
4. Rated loads marked with an asterisk ( * ) are limited by hydraulic capacity rather than
tipping load.
