Indicators and their priorities are as follows;
Table. Function indicators
1. Air preheating 2. Hammer selected (optional equipment)
3. Shear selected (optional equipment) 4. Overload indicator (optional equipment)
5. Boom float position (optional equipment) 6. Power boost selected
7. Rototilt selected (optional equipment)
Table. Warning indicators
1. Low engine oil pressure 2. Low coolant level
3. Overload warning (optional equipment)
Stop the lifting operation and reduce the
load.
4. Low engine oil level
5. Open attachment quick coupler (optional
equipment)
Stop work immediately if the bucket is still
attached to the attachment bracket.
6. Wrong battery charge
42
Instrument panels
Instrument panel, front
