7. High engine coolant temperature 8. Pattern changer warning
9. Clogged engine air filter 10. Seat belt
11. Low fuel level 12. High hydraulic oil temperature
13. AdBlue®/DEF warning 14. Regeneration needed
15. Regeneration, malfunction 16. High exhaust temperature during
regeneration
Table. Fixed indicators
1. Service mode selected (fixed position) 2. Message indicator (fixed position)
3. Pattern changer status (fixed position) 4. Pattern changer status (fixed position)
Instrument panels
Instrument panel, front
43
