WILLTEK 4403 - Page 333

Appendix A SCPI Command Reference
CONFigure subsystem
WCDMA Options Version 6.20
311
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:SEQuence
:ISLV
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:ALGOrithm
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:STEPsize
Description
This command defines the Inner loop power control sequence for the user sequence
ISL3 that could be selected using the command
:CONF:WCDM:MEAS:RFTX:INNE:SEQ:SELE ISL3.
Query
The query form of this command will return the Inner loop power control sequence
associated with user defined sequence ISL3 and that could be selected using the
command
:CONF:WCDM:MEAS:RFTX:INNE:SEQ:SELE ISL3.
Example
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:SEQuence:ISLC
"11111111110000000000"
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:SEQuence:ISLC?
Value returned in this example: "11111111110000000000"
Syntax
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:SEQuence:ISLV
<string1>
Parameters
string1 is a string, defining the inner loop power control sequence.
The maximum length of string1 is 20 characters.
The default for string1 is "00000000001111111111"
.
Description
This command defines the inner loop power control sequence for the user sequence
ISL5 that could be selected using the command
:CONF:WCDM:MEAS:RFTX:INNE:SEQ:SELE ISL5
.
Query
The query form of this command will return the inner loop power control sequence
associated with user defined sequence ISL5 and that could be selected using the
command
:CONF:WCDM:MEAS:RFTX:INNE:SEQ:SELE ISL5.
Example
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:SEQuence:ISLV
"11111111110000000000"
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:SEQuence:ISLV?
Value returned in this example: "11111111110000000000"
Syntax
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:ALGOrithm
<PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ALGO1|ALGO2
Default is ALGO1
.
Description
This command selects the TPC algorithm for inner loop power control.
Query
The query form of this command will return the current selected inner loop power
control algorithm.
Example
:CONF:WCDM:MEAS:RFTX:INNE:ALGO ALGO2
:CONF:WCDM:MEAS:RFTX:INNE:ALGO?
Value returned in this example: "ALGO2"
.
Syntax
:CONFigure:WCDMa:MEASure:RFTX:INNErloop:STEPsize
<PredefExp>
