Appendix A SCPI Command Reference
CONFigure subsystem
314 WCDMA Options Version 6.20
:CONFigure:WCDMa:MEASure:POLar:SEGMent:LENGth
:CONFigure:WCDMa:MEASure:POLar:SEGMent:STARt
:CONFigure:WCDMa:MEASure:POLar:WINDow:SIZe
:CONFigure:WCDMa:MEASure:POLar:WINDow:OFFSet
Syntax
:CONFigure:WCDMa:MEASure:POLar:SEGMent:LENGth <Int1>
Parameters
Int1 is an integer number. The minimum value is 200, the maximum value 2048.
The default value is 200.
Description
This command sets the segment length in μsec for polar calibration measurement.
Query
The query form of this command will return the current setting of the Willtek 4400.
The string delivered will contain one integer number.
Example
:CONF:WCDM:MEAS:POL:SEGM:LENG 500
:CONF:WCDM:MEAS:POL:SEGM:LENG?
Value returned in this example: 500
.
Syntax
:CONFigure:WCDMa:MEASure:POLar:SEGMent:STARt <Int1>
Parameters
Int1 is an integer number. The minimum value is 1, the maximum value 300. The
default value is 1.
Description
This command sets the segment to start polar calibration measurement at, this is
required due to limited sample window size.
Query
The query form of this command will return the current setting of the Willtek 4400.
The string delivered will contain one integer number.
Example
:CONF:WCDM:MEAS:POL:SEGM:STAR 1
:CONF:WCDM:MEAS:POL:SEGM:STAR?
Value returned in this example: 1
.
Syntax
:CONFigure:WCDMa:MEASure:POLar:WINDow:SIZe <Int1>
Parameters
Int1 is an integer number. The minimum value is 50, the maximum value 90. The
default value is 50.
Description
This command sets the window size in percent for polar calibration measurement.
Query
The query form of this command will return the current setting of the Willtek 4400.
The string delivered will contain one integer number.
Example
:CONF:WCDM:MEAS:POL:WIND:SIZ 60
:CONF:WCDM:MEAS:POL:WIND:SIZ?
Value returned in this example: 60
.
Syntax
:CONFigure:WCDMa:MEASure:POLar:WINDow:OFFSet <Int1>
Parameters
Int1 is an integer number. The minimum value is 5, the maximum value 50. The
default value is 5.
Description
This command sets the window offset in percent for polar calibration measurement.
