Appendix A SCPI Command Reference
MEASure subsystem
332 WCDMA Options Version 6.20
:MEASure:ARRay:PSUPply:ALL
Description
Performs the power supply measurements specified with the
:CONF:MEAS:GRO:PSUP command for a specific number of times (set with the
int1 parameter). To read out the entire measurement results array, use the
:FETCh:PSUP:GROup command.
Notes
– To perform any power and current consumption measurements on your Willtek
4400, the MS Power Supply and Current Measurements Option must be installed.
– For further details regarding group measurements, please refer to section
“:MEASure:...:GROup” on page 244.
Query
The query form of this command will start the sequence of power/current consump-
tion measurements as specified with the :CONF:MEAS:GRO:PSUP command for
a specific number of times (set with the int1 parameter). The order of the mea-
surement result values returned is as described below (see command
:MEAS:PSUP:ALL).
Example
:CONF:MEAS:GRO:PSUP ACUR,APOW
:MEASure:ARRay:PSUP:GROup?
In this example, the group of measurements is defined by a power consumption
measurement combined with a current consumption measurement. The measure-
ment result string returned is: "863.6,304.2".
Because of the internal order, the first measurement result value delivered back is
the power consumption, the second one the average current consumption measure-
ment.
Syntax
:MEASure:ARRay:PSUPply:ALL <int1>
Parameters
int1 is an integer.
The minimum value for int1 is 0, the maximum value is 100. The default value for
int1 is 0.
Description
Performs all measurements of the power and current consumption tests for a specific
number of times (set with the int1 parameter). To read out the latest measurement
results, use the :FETCh:PSUP:ALL command.
The power supply/current measurement tests performed by this command are:
APOW for the average power consumption measurement, measured in mW;
ACUR for the average current consumption measurement in mA,
PCUR for the peak current consumption in mA.
Notes
– Any power and current consumption measurement will need the MS Power Sup-
ply and the Current Measurement Options to be installed on your Willtek 4400.
– For further details regarding group measurements, please refer to section
“:MEASure:...:GROup” on page 244.
Query
The query form of this command starts the measurements for a specific number of
times (set with the int1 parameter). The order of these measurement result values
delivered back is as follows:
– APOW, representing the average power consumption in mW,
– ACUR, representing the average current consumption in mA,
– PCUR, representing the peak current consumption in mA.
