WILLTEK 4403 - Page 363

Appendix A SCPI Command Reference
MEASure subsystem
WCDMA Options Version 6.20
341
:MEASure:WCDMa[:CONTinuous]:RFTX:CODedomain:PCDe
:MEASure:WCDMa[:CONTinuous]:RFTX:CODedomain
:IPOWer[:DATa]
:MEASure:WCDMa[:CONTinuous]:RFTX:CODedomain:IPOWer
:AVG
Query
There is no query form of this command available.
Example
:MEASure:WCDMa:RFTX:OPENloop
Starts the open loop power measurement, then a loopback or speechcall has to be
established to measure the PRACH.
:FETC:WCDM:RFTX:OPEN? will deliver the measured value for open loop power.
Syntax
:MEASure:WCDMa[:CONTinuous]:RFTX:CODedomain:PCDe
Parameters
There are no parameters.
Description
It starts a continuous Peak Code Domain Error measurement.
Query
The query form of this command will return a floating point value with the result
in dB.
Example
:MEAS:WCDM:RFTX:COD:PCD?
Returns the measured PCDE value, e.g. -47.23
.
Syntax
:MEASure:WCDMa[:CONTinuous]:RFTX
:CODedomain:IPOWer[:DATa]
Parameters
There are no parameters.
Description
Starts a continuous measurement of the code domain power levels of the I-plane
code channels. To read out the latest measurement result, use
FETC:WCDM:RFTX:COD:IPOW[:DATA] command.
Query
This query command will start the measurement and return a result value as soon as
the first measurement has been completed. The result delivered will contain an array
of 4 till 256 floating point numbers, depending on the spreading factor.
Example
:MEAS:WCDM:RFTX:COD:IPOW?
Syntax
:MEASure:WCDMa[:CONTinuous]:RFTX:CODedomain:IPOWer
:AVG <Int1>
Parameters
Int1 is an integer. The minimum value for Int1 is 0, the maximum value is 100.
The default value is 0.
Description
Starts a continuous measurement of the Code Domain Power levels of the I-plane
code channels averaged over <Int1> measurements. To read out the latest mea-
surement result, use FETC:WCDM:RFTX:COD:IPOW? command.
Query
This query command will start the measurement and return a result value as soon as
<Int1> measurements has been completed. The result delivered will contain an
array of 4 till 256 floating point numbers, depending on the spreading factor.
Example
:MEAS:WCDM:RFTX:COD:IPOW:AVG 10?
