Appendix A SCPI Command Reference
MEASure subsystem
356 WCDMA Options Version 6.20
:MEASure:WCDMa:ARRay:UEReport:TXPOwer
:MEASure:WCDMa:ARRay:UEReport:RTTDifference
:MEASure:WCDMa:ARRay:UEReport:TRCH:BLER
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Reports the path loss between Node B and UE, estimated by the UE.
Query
The query form of this command will perform the measurement the specified number
of times and return the results.
Example
:MEAS:WCDM:ARR:UER:PLOS? 3
Starts the measurement and returns the result, e.g. 75,46,128
.
Syntax
:MEASure:WCDMa:ARRay:UEReport:TXPOwer <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Reports the UE transmit power.
Query
The query form of this command will perform the measurement the specified number
of times and return the results.
Example
:MEAS:WCDM:ARR:UER:TXPO? 4
Starts the measurement and returns the result, e.g. 66,75,43,28
.
Syntax
:MEASure:WCDMa:ARRay:UEReport:RTTDifference <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Reports the UE measured RX-Time-Difference between UL and DL signal.
Query
The query form of this command will perform the measurement the specified number
of times and return the results.
Example
:MEAS:WCDM:ARR:UER:RTTD? 5
Starts the measurement and returns the result, e.g.
854,966,1075,943,1128.
Syntax
:MEASure:WCDMa:ARRay:UEReport:TRCH:BLER <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Reports the UE estimated BLER value for the Transport Channel defined with
CONFigure:WCDMa:MEASure:UEReport:TRCH
.
Query
The query form of this command will perform the measurement the specified number
of times and return the results.
Example
:MEAS:WCDM:ARR:UER:TRCH:BLER? 2
Starts the measurement and returns the result, e.g. 0,2
.
