Appendix A SCPI Command Reference
MEASure subsystem
WCDMA Options Version 6.20
355
:MEASure:WCDMa:ARRay:UEReport:CPICh:ECNO
:MEASure:WCDMa:ARRay:UEReport:CPICh:RSCP
:MEASure:WCDMa:ARRay:UEReport:PLOSs
Query
The query form of this command starts the measurements and - after all 6 measure-
ments have been completed and all measurement results obtained - delivers a string,
containing 6 measurement result values, separated with commas. The order and type
of these measurement result values delivered is as follows:
1. CPICh ECNO, floating point real number representing UE measured normalized
chip energy per noise value of the P-CPICH,
2. CPICh RSCP, floating point real number representing UE measured received sig-
nal code power of the P-CPICH,
3. PLOSs, floating point real number representing the path loss between Node B and
UE, estimated by the UE,
4. TXPower, floating point real number representing the UE transmit power,
5. RTTDifference, floating point real number representing UE measured RX-
Time-Difference between UL and DL signal,
6. TRCH BLER, floating point real number representing the UE estimated BLER
value for the Transport Channel defined with CONFigure:WCDMa:MEA-
Sure:UEReport:TRCH.
Note: For a further description of the single measurements, see description of the
related commands below.
Example
:MEAS:WCDM:ARR:UER:ALL? 2
All UE Report measurements will be performed in a sequence, e.g.
23,85,102,97,992,3,23,85,102,97,992,3.
Syntax
:MEASure:WCDMa:ARRay:UEReport:CPICh:ECNO <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Reports the UE measured normalized chip energy per noise value of the P-CPICH.
Query
The query form of this command will perform the measurement the specified number
of times and return the results.
Example
:MEAS:WCDM:ARR:UER:CPICh:ECNO? 7
Starts the measurement and returns the result, e.g.
31,43,16,5,43,28,31.
Syntax
:MEASure:WCDMa:ARRay:UEReport:CPICh:RSCP <Int1>
Parameters
Int1 is an integer. The minimum value for Int1
is 0, the maximum value is 100.
The default value is 0.
Description
Reports the UE measured received signal code power of the P-CPICH.
Query
The query form of this command will perform the measurement the specified number
of times and return the results.
Example
:MEAS:WCDM:ARR:UER:CPICh:RSCP? 6
Starts the measurement and returns the result, e.g.
31,43,66,75,43,28.
Syntax
:MEASure:WCDMa:ARRay:UEReport:PLOSs <Int1>
