Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
397
:CALCulate:PSUPply:APOWer:LIMit:STATe
:CALCulate:PSUPply:APOWer:LIMit:UPPer[:DATA]
:CALCulate:PSUPply:APOWer:LIMit:LOwer[:DATA]
Example
:CALC:PSUP:APOW:LIM:UPP 2.3
:CALC:PSUP:APOWer:LIM:LOW 0
:MEAS:ARRay:PSUP:APOWer 5
:CALC:PSUP:APOWer:LIM?
String returned in this example:"1"
This string delivered back indicates that there was a violation of the limits set.
Syntax
:CALCulate:PSUPply:APOWer:LIMit:STATe <PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF.
Default is ON.
Description
This command switches the check of the power consumption measurement result
values of the MEAS:PSUP:APOWer measurement against their user-definable lim-
its either ON or OFF.
Note: All current measurements require the MS Power Supply and Current Measure-
ment options to be installed on your Willtek 4400.
Query
There is no query form of this command available.
Example
:CALC:PSUP:APOW:LIM:STAT ON
Switches the limit check of the current measurement on.
Syntax
:CALCulate:PSUPply:APOWer:LIMit:UPPer[:DATA] <real1>
Parameters
real1 is a floating point real number. The minimum value is 0.0, the maxi-
mum is 2000.0. The resolution is 1, the default value is 2000.0.
Description
Sets the upper limit for the power consumption measurement. The physical dimen-
sion of the number stated is mW.
Query
The query form of this command is not available.
Example
:CALC:PSUP:APOW:LIM:UPP 100
Sets the upper limit of the power consumption measurement to 100 mW.
Syntax
:CALCulate:PSUPply:APOWer:LIMit:LOwer[:DATA] <real1>
Parameters
real1 is a floating point real number. The minimum value is 0.0, the maxi-
mum is 2000.0. The resolution is 1, the default value is 2000.0.
Description
Sets the lower limit for the power consumption measurement. The physical dimension
of the number stated is mW.
Query
The query form of this command is not available.
Example
:CALC:PSUP:APOW:LIM:LOW 10
Sets the lower limit of the power consumption measurement to 10 mW.
