Appendix A SCPI Command Reference
CALCulate Subsystem
398 WCDMA Options Version 6.20
:CALCulate:PSUPply:ACURrent:LIMit:STATe
:CALCulate:PSUPply:ACURrent:LIMit:UPPer[:DATA]
:CALCulate:PSUPply:ACURrent:LIMit:LOwer[:DATA]
:CALCulate:PSUPply:PCURrent:LIMit[:FAIL]?
Syntax
:CALCulate:PSUPply:ACURrent:LIMit:STATe <PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF.
Default is ON.
Description
This command switches the check of the current measurement result values of the
MEAS:PSUP:ACURrent measurement against their user-definable limits either
ON or OFF.
Note All current measurements require the MS Power Supply and Current Measure-
ment options to be installed on your Willtek 4400.
Query
The query form of this command is not available.
Example
:CALC:PSUP:ACUR:LIM:STAT ON
Switches the limit check of the average current measurement on.
Syntax
:CALCulate:PSUPply:ACURrent:LIMit:UPPer[:DATA] <real1>
Parameters
real1 is a floating point real number. The minimum value is 0.0, the maxi-
mum is 1000.0. The resolution is 1, the default value is 1000.0.
Description
Sets the upper limit for the average current measurement. The physical dimension of
the number stated is mA.
Query
The query form of this command is not available.
Example
:CALC:PSUP:ACUR:LIM:UPP 400
Sets the upper limit of the average current measurement to 400 mA.
Syntax
:CALCulate:PSUPply:ACURrent:LIMit:LOwer[:DATA] <real1>
Parameters
real1 is a floating point real number. The minimum value is 0.0, the maxi-
mum is 1000.0. The resolution is 1, the default value is 0.0.
Description
Sets the lower limit for the peak current consumption measurement. The physical
dimension of the number stated is mA.
Query
The query form of this command is not available.
Example
:CALC:PSUP:ACUR:LIM:LOW 10
Sets the lower limit of the current consumption measurement to 10 mA.
Syntax
:CALCulate:PSUPply:PCURrent:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
