Appendix A SCPI Command Reference
CALCulate Subsystem
406 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:STATe
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:UPPer:[DATA]
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:LOWer:[DATA]
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:MAXimum:UPPer:
[DATA]
Syntax
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:STATe
<PredefExp>
Parameters
PredefExp
can take on one of the following values: ON|OFF. The default is ON.
Description
This command switches the check of the measurement result values of the mean
power measurement against their user-definable limits either ON or OFF.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:POW:MEAN:LIM:STAT ON
Switches the limit check for the frequency error measurement on.
Syntax
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:UPPer:[DATA]
<real>
Parameters
real
is a floating point real number. Its minimum value is -120.0, the maximum
is 50.0, the resolution is 0.1 and the default is 34.0.
Description
Sets the upper limit for the mobile's RF output mean power. The physical dimension
of the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:POW:MEAN:LIM:UPP 12.5
:CALC:WCDM:RFTX:POW:MEAN:LIM:UPP?
Returns 12.5
.
Syntax
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:LOWer:[DATA]
<real>
Parameters
real is a floating point real number. Its minimum value is -120.0, the maximum
is 50.0, the resolution is 0.1 and the default is -60.0
.
Description
Sets the lower limit for the mobile's RF output mean power. The physical dimension of
the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:POW:MEAN:LIM:LOW -32.5
:CALC:WCDM:RFTX:POW:MEAN:LIM:LOW?
Returns -32.5
.
Syntax
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit
:MAXimum:UPPer:[DATA] <Real1>,<Real2>,<Real3>,<Real4>
