Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
407
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:MAXimum:LOWer:
[DATA]
:CALCulate:WCDMa:RFTX:POWer:MINimum:LIMit:UPPer:[DATA]
Parameters
realx are floating point real numbers. The minimum value of <Real1> is 10.0,
the maximum is 44.0 and the default is 34.0. The minimum value of <Real2> is
4.0, the maximum is 38.0 and the default is 28.0. The minimum value of
<Real3> is 1.0, the maximum is 35.0 and the default is 25.0. The minimum
value of <Real4> is -1.0, the maximum is 33.0 and the default is 23.0. The
resolution of all values is 0.1.
Description
Sets the upper limits for the mobile's RF output mean maximum power for the power
classes 1, 2, 3 and 4. The physical dimension of the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:POW:MEAN:LIM:MAX:UPP 35,29,26,24
:CALC:WCDM:RFTX:POW:MEAN:MAX:LIM:UPP?
Returns 35.0,29.0,26.0,24.0
.
Syntax
:CALCulate:WCDMa:RFTX:POWer:MEAN:LIMit:MAXi-
mum:LOWer:[DATA] <Real1>,<Real2>,<Real3>,<Real4>
Parameters
realx
are floating point real numbers. The minimum value of <Real1> is 10.0,
the maximum is 44.0 and the default is 30.0. The minimum value of <Real2> is
4.0, the maximum is 38.0 and the default is 24.0. The minimum value of
<Real3> is 1.0, the maximum is 35.0 and the default is 21.0. The minimum
value of <Real4> is -1.0, the maximum is 33.0 and the default is 19.0. The
resolution of all values is 0.1
.
Description
Sets the lower limits for the mobile's RF output mean maximum power for the power
classes 1, 2, 3 and 4. The physical dimension of the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:POW:MEAN:LIM:MAX:LOW 29,23,20,18
:CALC:WCDM:RFTX:POW:MEAN:MAX:LIM:LOW?
Returns 29.0,23.0,20.0,18.0
.
Syntax
:CALCulate:WCDMa:RFTX:POWer:MINimum:LIMit:UPPer:[DATA]
<real>
Parameters
real
is a floating point real number. Its minimum value is -120.0, the maximum
is 0.0, the resolution is 0.1 and the default is -50.0.
Description
Sets the upper limit for the mobile's RF mean minimum power. The physical dimen-
sion of the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:POW:MIN:LIM:UPP -40.5
:CALC:WCDM:RFTX:POW:MIN:LIM:UPP?
Returns
-40.5.
