:CALCulate:WCDMa:RFTX:POWer:MINimum:LIMit:LOWer:[DATA]
CALCulate:WCDMa:RFTX:POWer:PEAK:LIMit[:FAIL]
:CALCulate:WCDMa:RFTX:POWer:PEAK:LIMit:STATe
:CALCulate:WCDMa:RFTX:POWer:PEAK:LIMit:UPPer:[DATA]
Syntax
:CALCulate:WCDMa:RFTX:POWer:MINimum:LIMit:LOWer:[DATA]
<real>
Parameters
real
is a floating point real number. Its minimum value is -120.0, the maximum
is 0.0, the resolution is 0.1 and the default is -120.0
.
Description
Sets the lower limit for the mobile's RF mean minimum power. The physical dimen-
sion of the number stated is dBm.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:POW:MIN:LIM:LOW -60.5
:CALC:WCDM:RFTX:POW:MIN:LIM:LOW?
Returns -60.5
.
Syntax
:CALCulate:WCDMa:RFTX:POWer:PEAK:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the
:MEAS:WCDMA:ARR:RFTX:POW:PEAK measurement violated the defined
limits.
Example
:MEAS:WCDMA:ARR:RFTX:PEAK:POW 20
:CALC:WCDM:RFTX:POW:PEAK:LIM?
Returns 0 if any of the 20 power measurements was out of limits, and
1 if all results
were within limits.
Syntax
:CALCulate:WCDMa:RFTX:POWer:PEAK:LIMit:STATe
<PredefExp>
Parameters
PredefExp can take on one of the following values: ON|OFF
. The default is ON.
Description
This command switches the check of the measurement result values of the peak
power measurement against their user-definable limits either ON or OFF.
Query
There is a query form whicht returns the sotred settings.
Example
:CALC:WCDM:RFTX:POWer:PEAK:LIM:STAT ON
Switches the limit check for the frequency error measurement on
Syntax
:CALCulate:WCDMa:RFTX:POWer:PEAK:LIMit:UPPer:[DATA]
<real>
Parameters
real is a floating point real number. Its minimum value is -120.0, the maximum
is 50.0, the resolution is 0.1 and the default is 34.0.
