Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
413
:CALCulate:WCDMa:RFTX:MODQuality:EPEAk:LIMit:LOWer:[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit[:FAIL]
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit:STATe
Query
There is query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:EPEA:LIM:UPP 200
:CALC:WCDM:RFTX:MODQ:EPEA:LIM:UPP?
Returns 200
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:EPEAk:LIMit:LOWer:
[DATA] <Real1>
Parameters
Real1 is a floating point real number. Its minimum value is 0.0, the maximum is
200.0, the resolution is 0.1, the default is value is 0.0.
Description
Sets the lower limit for the EVM peak vector error measurement. The physical dimen-
sion of the number is stated as a percentage.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:EPEA:LIM:LOW 0
:CALC:WCDM:RFTX:MODQ:EPEA:LIM:LOW?
Returns 0 in this example.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the
:MEAS:WCDMA:ARR:RFTX:MODQ:MRMS measurement violated its limits.
Example
:MEAS:WCDMA:ARR:RFTX:MODQ:MRMS 20
:CALC:WCDM:RFTX:MODQ:MRMS:LIM?
The query returns 1 if any of the measurement results was out of limits, or 0 if none
of the results was out of limits.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit:STATe
<PredefExp>
Parameters
PredefExp may take on one of the following predefined expressions:
ON|OFF.
The default is ON.
Description
This command switches the check of the measurement result values of the magnitude
RMS vector error measurement against their user-definable limits either ON or OFF.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:MRMS:LIM:STAT ON
Switches the limit check for the magnitude RMS-averaged vector error measurement
on.
