Appendix A SCPI Command Reference
CALCulate Subsystem
414 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit:UPPer:[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit:LOWer:[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:MPEAk:LIMit[:FAIL]
:CALCulate:WCDMa:RFTX:MODQuality:MPEAk:LIMit:STATe
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit:UPPer:
[DATA] <Real1>
Parameters
Real1 is a floating point real number. The minimum value for parameter is 0.0, the
maximum is 200.0, the resolution is 0.1, the default is value is 17.5.
Description
Sets the upper limit for the magnitude RMS average vector error. The physical dimen-
sion of the number stated is percentage.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:MRMS:LIM:UPP 200
:CALC:WCDM:RFTX:MODQ:MRMS:LIM:UPP?
The query returns the previously set value 200.0
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:MRMS:LIMit:LOWer:
[DATA] <Real1>
Parameters
Real1
is a floating point real number. The minimum value for parameter is 0.0, the
maximum is 200.0, the resolution is 0.1, the default is value is 0.0.
Description
Sets the lower limit for the magnitude RMS average vector error. The physical dimen-
sion of the number stated is percentage.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:MRMS:LIM:LOW 200
:CALC:WCDM:RFTX:MODQ:MRMS:LIM:LOW?
The query returns the previously set value 200.0
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:MPEAk:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the
:MEAS:WCDMA:ARR:RFTX:MODQ:MPEA measurement violated its limits.
Example
:MEAS:WCDMA:ARR:RFTX:MODQ:MPEA 20
:CALC:WCDM:RFTX:MODQ:MPEA:LIM?
Returns 0 if all 20 results are within limits, or 1 if any result is outside the limits.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:MPEAk:LIMit:STATe
<PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF
. Default is
ON.
