Appendix A SCPI Command Reference
CALCulate Subsystem
416 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFTX:MODQuality:PRMS:LIMit:STATe
:CALCulate:WCDMa:RFTX:MODQuality:PRMS:LIMit:UPPer:
[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:PRMS:LIMit:LOWer:
[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit[:FAIL]
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:PRMS:LIMit:STATe
<PredefExp>
Parameters
PredefExp
may take on one of the following predefined expressions: ON|OFF.
The default is ON.
Description
This command switches the check of the measurement result values of the Phase
RMS vector error measurement against their user-definable limits either ON or OFF.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:PRMS:LIM:STAT ON
Switches the limit check for the Phase RMS-averaged vector error measurement on.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:PRMS:LIMit:UPPer:
[DATA] <Real1>
Parameters
Real1 is a floating point real number. The minimum value for parameter is 0.0, the
maximum is 200.0, the resolution is 0.1, the default is value is 10.0.
Description
Sets the upper limit for the Phase RMS average vector error. The physical dimension
of the number stated is percentage.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:PRMS:LIM:UPP 200
:CALC:WCDM:RFTX:MODQ:PRMS:LIM:UPP?
The query returns the previously set value 200.0
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:PRMS:LIMit:LOWer:
[DATA] <Real1>
Parameters
Real1
is a floating point real number. The minimum value for parameter is 0.0, the
maximum is 200.0, the resolution is 0.1, the default is value is 0.0.
Description
Sets the lower limit for the Phase RMS average vector error. The physical dimension
of the number stated is percentage.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:PRMS:LIM:LOW 200
:CALC:WCDM:RFTX:MODQ:PRMS:LIM:LOW?
The query returns the previously set value 200.0
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit[:FAIL]?
Parameters
There are no parameters.
