Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
417
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit:STATe
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit:UPPer:
[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit:LOWer:
[DATA]
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the
:MEAS:WCDMA:ARR:RFTX:MODQ:PPEA measurement violated its limits.
Example
:MEAS:WCDMA:ARR:RFTX:MODQ:PPEA 20
:CALC:WCDM:RFTX:MODQ:PPEA:LIM?
Returns 0 if all 20 results are within limits, or 1 if any result is outside the limits.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit:STATe
<PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF. Default is ON
.
Description
This command switches the check of the measurement result values of the measure-
ment against their user-definable limits either ON or OFF.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:PPEA:LIM:STAT ON
Switches the limit check for the phase peak vector error measurement on.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit:UPPer:
[DATA]
Parameters
Real1 is a floating point real number. Its minimum value is 0.0, the maximum is
200.0, the resolution is 0.1, and the default is value is 45.0.
Description
Sets the upper limit for the phase peak vector error measurement. The physical
dimension of the number is stated as a percentage.
Query
There is query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:PPEA:LIM:UPP 200
:CALC:WCDM:RFTX:MODQ:PPEA:LIM:UPP?
Returns 200
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:PPEAk:LIMit:LOWer:
[DATA] <Real1>
Parameters
Real1
is a floating point real number. Its minimum value is 0.0, the maximum is
200.0, the resolution is 0.1, the default is value is 0.0.
Description
Sets the lower limit for the Phase peak vector error measurement. The physical
dimension of the number is stated as a percentage.
Query
There is a query form which returns the stored settings.
