Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
419
:CALCulate:WCDMa:RFTX:MODQuality:RHO:LIMit:LOWer
:[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit
[:FAIL]
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit
:STATe
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit
:UPPer:[DATA]
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:RHO:LIMit:LOWer:[DATA]
<Real1>
Parameters
Real1 is a floating point real number. The minimum value for this parameter is 0.0,
the maximum is 1.0, the resolution is 0.0001, the default is value is 0.944.
Description
Sets the lower limit for the waveform quality measurement.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:RHO:LIM:LOW 0.944
:CALC:WCDM:RFTX:MODQ:RHO:LIM:LOW?
Returns 0.944
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the origin off-
set measurement exceeds the limits.
Example
:MEAS:WCDMA:ARR:RFTX:MODQ:IQOF? 20
:CALC:WCDM:RFTX:MODQ:IQOF:LIM?
The query returns 1 if any of the measurement results was out of limits, or 0 if none
of the results was out of limits.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit:STATe
<PredefExp>
Parameters
PredefExp
is one of the following predefined expressions: ON|OFF. The default is
ON
.
Description
This command switches the check of the measurement result values of the origin off-
set measurement against their user-definable limits either ON or OFF.
Query
There is no query form of this command available.
Example
:CALC:WCDM:RFTX:MODQ:IQOF:LIM:STAT ON
Switches the limit check for the origin offset measurement on.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit:UPPer:[
DATA] <Real1>
