Appendix A SCPI Command Reference
CALCulate Subsystem
420 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit
:LOWer:[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
[:FAIL]
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
:STATe
Parameters
Real1
is a floating point real number. The minimum value for parameter is 0.0, the
minimum is 0.0, the resolution is 0.1, the default is value is 0.0
.
Description
Sets the upper limit for the origin offset measurement. The physical dimension of the
number stated is dBc.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:IQOF:LIM:UPP 0
:CALC:WCDM:RFTX:MODQ:IQOF:LIM:UPP?
Returns 0 in this case
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQOFfset:LIMit:LOWer:[
DATA] <Real1>
Parameters
Real1 is a floating point real number. Its minimum value is -99.0, the maximum
is 0.0, the resolution is 0.1, the default is value is -99.0.
Description
Sets the lower limit for the origin offset measurement. The physical dimension of the
number stated is dBc.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:IQOF:LIM:LOW -60.0
:CALC:WCDM:RFTX:MODQ:IQOF:LIM:LOW?
Returns
-60.0.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the IQ imbal-
ance measurement exceeds the limits.
Example
:MEAS:WCDMA:ARR:RFTX:MODQ:IQIM? 20
:CALC:WCDM:RFTX:MODQ:IQIM:LIM?
The query returns 1 if any of the measurement results was out of limits, or 0 if none
of the results was out of limits.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
:STATe <PredefExp>
Parameters
PredefExp
is one of the following predefined expressions: ON|OFF. Default is ON.
