Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
421
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
:UPPer:[DATA]
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
:LOWer:[DATA]
CALCulate:WCDMa:RFTX:INNErloop:LIMit[:FAIL]
Description
This command switches the check of the measurement result values of the IQ imbal-
ance measurement against their user-definable limits either ON or OFF.
Query
There is no query form of this command available.
Example
:CALC:WCDM:RFTX:MODQ:IQIM:LIM:STAT ON
Switches the limit check for the IQ imbalance measurement on.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
:UPPer:[DATA] <Real1>
Parameters
Real1 is a floating point real number. The minimum value for parameter is 0.0, the
maximum is 0.0, the resolution is 0.1, the default is value is 0.0.
Description
This command sets the upper limit for the IQ imbalance measurement. The physical
dimension of the number stated is dB.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:IQIM:LIM:UPP 0
:CALC:WCDM:RFTX:MODQ:IQIM:LIM:UPP?
Returns 0
.
Syntax
:CALCulate:WCDMa:RFTX:MODQuality:IQIMbalance:LIMit
:LOWer:[DATA] <PredefExp>
Parameters
PredefExp is a floating point real number. The minimum value is -99.0, the
maximum is 0.0, the resolution is 0.1, the default is value is -99.0.
Description
This command sets the lower limit for the IQ imbalance measurement. The physical
dimension of the number stated is dB.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:MODQ:IQIM:LIM:LOW -99.0
:CALC:WCDM:RFTX:MODQ:IQIM:LIM:LOW?
Returns
-99.0.
Syntax
:CALCulate:WCDMa:RFTX:INNErloop:LIMit[:FAIL]?
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the inner loop
power control measurement exceeds the limits.
