Appendix A SCPI Command Reference
CALCulate Subsystem
422 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFTX:INNErloop:LIMit:STATe
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCUp:UPPer
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCUp:LOWer
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCDown:UPPer
Example
:MEAS:WCDM:ARR:RFTX:INNE? 10
:CALC:WCDM:RFTX:INNE:LIM?
The query returns 1, f any of the measurement results was out of limits, or 0 if none
of the results was out of limits.
Syntax
:CALCulate:WCDMa:RFTX:INNErloop:LIMit:STATe <PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF
. Default is
ON
.
Description
This command switches the check of the measurement result values of the inner loop
Power Control measurement against their user-definable limits either ON or OFF.
Query
There is no query form of this command available.
Example
:CALC:WCDM:RFTX:INNE:LIM:STAT ON
Switches the limit check for the inner loop power control ratio measurement on.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCUp
:UPPer <Real1>
Parameters
Real1 is a floating point real number. The minimum value for the parameter is 0.0,
the maximum is 3.0, the resolution is 0.1, the default is value is 1.5.
Description
Sets the upper limit for TPC_cmd +1 for the 1 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCU:UPP 0
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCU:UPP?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCUp
:LOWer <Real1>
Parameters
Real1
is a floating point real number. The minimum value for the parameter is 0.0,
the maximum is 3.0, the resolution is 0.1, the default is value is 1.5.
Description
Sets the upper limit for TPC_cmd +1 for the 1 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCU:LOW 0
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCU:LOW?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCDown
:UPPer <Real1>
