Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
423
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCDown:LOWer
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCZero:UPPer
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCZero:LOWer
Parameters
Real1
is a floating point real number. The minimum value for the parameter is -
3.0, the maximum is 0.0, the resolution is 0.1, the default is value is 1.5.
Description
Sets the upper limit for TPC_cmd -1 for the 1 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCD:UPP 0
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCD:UPP?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCDown
:LOWer <Real1>
Parameters
Real1 is a floating point real number. The minimum value for the parameter is -
1.5, the maximum is 0.0, the resolution is 0.1, the default is value is 0.5.
Description
Sets the lower limit for TPC_cmd -1 for the 1 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCD:LOW 0
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCDU:LOW?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB1:TPCZero:UPPer
<Real1>
Parameters
Real1
is a floating point real number. The minimum value for the parameter is
-1.0, the maximum is 1.0, the resolution is 0.1, the default is value is 0.5.
Description
Sets the upper limit for TPC_cmd 0 for the 1 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCZero:UPP 0
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCZero:UPP?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCZero
:LOWer <Real1>
Parameters
Real1 is a floating point real number. The minimum value for the parameter is
-1.0, the maximum is 1.0, the resolution is 0.1, the default is value is -0.5.
Description
Sets the lower limit for TPC_cmd 0 for the 1 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCZero:LOW 0
CALCul:WCDM:RFTX:INNE:LIM:DB1:TPCZero:LOW?
Returns 0 in this case.
