Appendix A SCPI Command Reference
CALCulate Subsystem
424 WCDMA Options Version 6.20
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCUp:UPPer
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCUp:LOWer
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCDown:UPPer
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCDown:LOWer
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCUp
:UPPer <Real1>
Parameters
Real1 is a floating point real number. The minimum value for parameter is 0.0, the
maximum is 6.0, the resolution is 0.1, the default is value is 3.0.
Description
Sets the upper limit for TPC_cmd +1 for the 2 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCU:UPP 0
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCU:UPP?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCUp
:LOWer <Real1>
Parameters
Real1 is a floating point real number. The minimum value for parameter is 0.0, the
maximum is 6.0, the resolution is 0.1, the default is value is 1.0.
Description
Sets the lower limit for TPC_cmd +1 for the 2 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCU:LOW 0
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCU:LOW?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCDown:UPPer
<Real1>
Parameters
Real1 is a floating point real number. The minimum value for parameter is -6.0,
the maximum is 0.0, the resolution is 0.1, the default is value is -1.0.
Description
Sets the upper limit for TPC_cmd -1 for the 2 dB step.
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCD:UPP 0
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCD:UPP?
Returns 0 in this case.
Syntax
CALCulate:WCDMa:RFTX:INNErloop:LIMit:DB2:TPCDown:LOWer
<Real1>
Parameters
Real1 is a floating point real number. The minimum value for parameter is -6.0,
the maximum is 0.0, the resolution is 0.1, the default is value is -3.0.
Description
Sets the lower limit for TPC_cmd -1 for the 2 dB step.
