Appendix A SCPI Command Reference
CALCulate Subsystem
WCDMA Options Version 6.20
425
:CALCulate:WCDMa:RFTX:OPEN:LIMit:STATe
:CALCulate:WCDMa:RFTX:OPEN:LIMit:RELative:[DATA]
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit[:FAIL]
Query
There is a query form which returns the stored settings.
Example
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCD:LOW 0
CALCul:WCDM:RFTX:INNE:LIM:DB2:TPCDU:LOW?
Returns 0 in this case.
Syntax
:CALCulate:WCDMa:RFTX:OPEN:LIMit:STATe <PredefExp>
Parameters
PredefExp can take on one of the following values: ON|OFF
. The default is ON.
Description
This command switches the check of the measurement result values of the open loop
power measurement against their user-definable limits either ON or OFF.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:OPEN:LIM:STAT ON
Switches the limit check for the open loop power measurement on.
Syntax
:CALCulate:WCDMa:RFTX:OPEN:LIMit:RELative:[DATA] <real>
Parameters
real is a floating point real number. Its minimum value is 0.0, the maximum is
15.0, the resolution is 0.1 and the default is 9.0.
Description
Sets the lower and upper limit for the mobile's open loop power. The physical dimen-
sion of the number is stated as dB relative to the estimated Preamble Initial Power. If
the value is set to 9.0 the lower limit is set to -9.0dB and the upper is set to +9dB rel-
ative to estimated preamble initial power.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:OPEN:LIM:REL 9.0
:CALC:WCDM:RFTX:OPEN:LIM:REL?
Returns 0.0
.
Syntax
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit[:FAIL]
Parameters
There are no parameters.
Description
There is solely a query form of this command available.
Query
This command delivers a boolean number in a string which indicates if the peak code
domain error measurement exceeds the limits.
Example
:MEAS:WCDMA:ARR:RFTX:COD:PCD? 20
:CALC:WCDM:RFTX:COD:PCD:LIM?
The query returns 1 if any of the measurement results was out of limits, or a 0 if none
of the results was out of limits.
