Appendix A SCPI Command Reference
CALCulate Subsystem
426 WCDMA Options Version 6.20
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:STATe
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:UPPer:[DATA]
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:LOWer:[DATA]
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:LOWer:[DATA]
Syntax
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:STATe
<PredefExp>
Parameters
PredefExp is one of the following predefined expressions: ON|OFF
. Default is ON.
Description
This command switches the check of the measurement result values of the peak code
domain error measurement against their user-definable limits either ON or OFF.
Query
There is no query form of this command available.
Example
:CALC:WCDM:RFTX:COD:PCD:LIM:STAT ON
Switches the limit check for the peak code domain error measurement on.
Syntax
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:UPPer
:[DATA] <Real1>
Parameters
Real1 is a floating point real number. The minimum value for the parameter is -
120.0, the maximum is 0.0, the resolution is 0.1, the default is value is -15.0.
Description
This command sets the upper limit for the peak code domain error measurement. The
physical dimension of the number stated is dB.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:COD:PCD:LIM:UPP -32.0
:CALC:WCDM:RFTX:COD:PCD:LIM:UPP?
Returns -32.0
.
Syntax
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:LOWer
:[DATA] <Real1>
Parameters
Real1 is a floating point real number. The minimum value for the parameter is
-120.0, the maximum is 0.0, the resolution is 0.1, the default is value is -
120.0.
Description
This command sets the lower limit for the peak code domain error measurement. The
physical dimension of the number stated is dB.
Query
There is a query form which returns the stored settings.
Example
:CALC:WCDM:RFTX:COD:PCD:LIM:LOW -99.0
:CALC:WCDM:RFTX:COD:PCD:LIM:LOW?
Returns -99.0
.
Syntax
:CALCulate:WCDMa:RFTX:CODedomain:PCDe:LIMit:LOWer
:[DATA] <Real1>
Parameters
Real1 is a floating point real number. The minimum value for the parameter is
-120.0, the maximum is 0.0, the resolution is 0.1, the default is value is -
120.0.
