Appendix A SCPI Command Reference
RFANalyser subsystem
WCDMA Options Version 6.20
443
:RFANalyser:WCDMa:MODulation:WCDMa:SFORmat
:RFANalyser:WCDMa:NSTaircase:FREQuency
:RFANalyser:WCDMa:NSTaircase:UARFcn
Query
The query form of this command will return the current setting. The string delivered
back will contain one integer.
Example
:RFAN:WCDM:CCOD 10
:RFAN:WCDM:CCOD?
Value returned in this example: 10
.
Syntax
:RFANalyser:WCDMa:MODulation:WCDMa:SFORmat <int1>
Parameters
int1
is an integer number. The minimum value is 0, the maximum value 5. The ini-
tial default is 0.
Description
This command will set the slot format of the 4400 Analyzer.
Query
The query form of this command will return the current setting. The string delivered
back will contain one integer.
Example
:RFAN:WCDM:SFOR 2
:RFAN:WCDM:SFOR?
Value returned in this example: 2
.
Syntax
:RFANalyser:WCDMa:NSTaircase:FREQuency <Real1>
Parameters
Real1 is a floating point real number. The minimum value for Real1 is
430,000,000, the maximum value is 2,300,000,000. The minimum resolu-
tion for real1 is 10. The default value is 1,950,300,000.
Description
This command will set the Uplink frequency of the 4400 in Hz for Staircase Measure-
ments. The frequency of can be changed in steps of 10 Hz.
Query
The query form of this command will return the current setting. The string delivered
will contain one floating point real number.
Example
:RFAN:WCDM:NST:FREQ 1950000000
:RFAN:WCDM:NST:FREQ?
Value returned in this example: 1950000000
.
Syntax
:RFANalyser:WCDMa:NSTaircase:UARFcn <int1>
Parameters
int1 is an integer number. The minimum value is 0, the maximum value 9888. The
initial default is 9750.
Description
This command will set the Uplink channel number of the 4400 for Staircase measure-
ments.
Query
The query form of this command will return the current setting. The string delivered
back will contain one integer.
Example
:RFAN:WCDM:NST:UARF 7510
:RFAN:WCDM:NST:UARF?
Value returned in this example: 7510
.
