Xerox Phaser 3600

8-16 Phaser 3600 Printer Service Manual
Parts List
41 SHAFT M GEAR RETARD
42 SHAFT M COUPLING RETARD
43 PMO BEARING SHAFT 013N13841
44 GEAR REGI Z25
45
47 MEA UNIT FRAME LSU LOW (Sub-toner Low Sensor) 001N00500
47-1 FRAME M LSU LOWER (LSU Lower Cover)
47-2 PBA TONER SENSOR
47-3 TERMINAL P DEVE
47-4 PBA SUB COVER OPEN 130N01399
47-5 CAP M COVER OPEN 002N02729
48 ELA UNIT FEED 3X5 022N02174
48-1 HOLDER M SAW
48-2 GUIDE P TRANSFER FRONT
48-3 PLATE P SAW
48-4 SHAFT M ROLLER BELT
48-5 ROLLER M IDLE BELT
48-6 IEX SHAFT IDLE, F/UP
48-7 RUBBER BELT FEED
48-8 GUIDE M SHAFT BELT
49 ELA UNIT ROLLER IDLE 022N02349
49-1 FRAME M RETARD
49-2 HOLDER M RETARD
49-3 SPRING ETC PAD
49-4 BUSH M RETARD 2
49-5 HOUSING M RETARD
49-6 SHAFT RETARD
49-7 RING-E
49-8 PMO HUB OUT RETARD
49-9 SPRING TS
49-10 PMO HUB IN RETARD
49-11 RUBBER RETARD
50 ELA UNIT FEED2 IDLE (Feed 2 Idle Unit) 022N02176
50-1 HOLDER IDLE FEED2
50-2 CAP M IDLE FEED2
PL 1.3 Frame Assembly Parts List Table (continued)
Ite
m
No. Description Part Number
