Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 8-17
Parts List
50-3 SPRING ETC PAD
50-4 BUSH M RETARD
50-5 SHAFT IDLE FEED2
50-6 RING-E
50-7 ROLLER M IDLE FEED2
50-9 SHAFT HUB IN
51 STOPPER M KNOCK UP MP L
52 STOPPER M KNOCK UP MP R
53 RAIL M LEFT DUPLEX 032N00441
54 RAIL M RIGHT DUPLEX 032N00442
55 PMO BEARING SHAFT 013N13841
56 GEAR REGI E25
57 BEARING PICK UP
58 PMO ACTUATOR EMPTY (Paper Tray Empty Actuator) 120N00519
59 ELA UNIT PICK UP 022N02183
59-1 SHAFT PICK UP
59-2 MEA UNIT P/UP HOUSING (Pick Roller) 022N02177
59-2-1 PMO M IDLE PICK UP
59-2-3 RUBBER PICK UP
59-3 PMO M CAM PICKUP
59-4 SHAFT FEED 1
59-5 AS FEED 1 ROLL ASSY 022N02187
59-5-1 HOUSING M FEED1
59-5-2 RUBBER FEED1
59-6 GROUND P PICK UP MAIN
59-7 BEARING PICK UP
59-8 PMO BUSHING FEED
59-9 GUIDE P FRONT DUP PICKUP
59-10 GUIDE M SUPPORT PICKUP
60 ELA UNIT FEED2 022N02178
60-1 FRAME M PICK UP
60-2 PMO BUSHING FEED
60-3 SHAFT M FEED2
60-4 BEARING PICK UP
60-5 RUBBER ROLLER FEED2
PL 1.3 Frame Assembly Parts List Table (continued)
Ite
m
No. Description Part Number

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
