Xerox Phaser 3600 Service Manual

8-18 Phaser 3600 Printer Service Manual
Parts List
61 PBA SUB JOINT (Joint Card) 140N63022
62 CBF HARNESS TRAY OUT
63 CAP M POWER
64 CBF HARNESS INLET 152N11756
65 SHAFT M BELT GEAR
66 PMO BEARING SHAFT
67 GEAR M EXIT Z17
68 CAP M DEVE MOTOR
69 CBF HARNESS DUPLEX
71 CAP M WIRE PTL LOWER 021N02249
72 TERMINAL P PTL 116N00243
73 CBF HARNESS PTL
74
76 PBA SUB EXIT SENSOR (Fuser Exit Sensor) 130N01400
77 PBA FUSER SW (Fuser Interlock Switch) 130N01401
78 GUIDE M FRONT
79 TERMINAL P GUIDE FRONT
80 ELA UNIT FUSER 110V
ELA UNIT FUSER 220V
126N00293
126N00294
81 PMO GUIDE DEVE L
82 PMO GUIDE DEVE R
83 SPRING ETC GUIDE DEVE
84 TERMINAL P TR KESTREL
86 TERMINAL SPRING TR
87 PBA MAIN ZENER
88 CBF HARNESS EARTH
89 GROUND P ZENER
90 GROUND P FUSER
91 TERMINAL P HV CARDINAL
92 MEA UNIT TERMINAL TR
93 CBF HARNESS HVPS
94 IPR P GROUND OPC
95 PBA SUB EMPTY SENSOR (Paper Tray Empty Sensor) 140N63023
96 CBF HARNESS SENSOR
97 PBA SUB FEED SENSOR (Tray 1 FeedSensor) 140N63024
98 CAP M HV
PL 1.3 Frame Assembly Parts List Table (continued)
Ite
m
No. Description Part Number

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
