Xerox Phaser 3600 Service Manual

Phaser 3600 Printer Service Manual 8-21
Parts List
PL 1.4 Fuser Assembly Parts List Table
Item No. Description Part Number
1 ELA UNIT FUSER (110V)
ELA UNIT FUSER (220V)
126N00293
126N00294
2 SCREW-TAPTITE
3 THERMOSTAT 130N01537
4 SCREW-TAPTITE
5 HARNESS-FUSER
6 COVER-FUSER UP LAMP
7 PMO BUSHING TX
8 HOLDER -IDLE ROLLER
9 SPRING ETC ACTUATOR
10 PMO ROLLER UPPER DP
11 PMO ACTUATOR EXIT
12 GEAR-EXIT
13 HOLDER REAR LEVER
14 LABEL HOLD-REOPEN
15 ROLLER EXIT F_UP
16 PLATE ACTUATOR COVER
17 HOLDER-LEVEL R
18 GEAR IDLE
19 CAP ACTUATOR
20 GREASE-BEARING
21 RING E
22 GEAR-FUSER 2 LAMP
23 BRACKET LAMP-RIGHT
24 BEARING BALL
25 BRACKET FUSER-LAMP
26 RING CS
28 SPRING ETC-SEPARATION
29 GUIDE-CLAW POLY
30 COVER SLIDE SENSOR
31 TEX-SHAFT IDLE F/UP
32 PEX ROLLERF/UP
33 SPRING-TS
34 HOLDER-LEVER L
35 GROUND FUSER BRUSH

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
