Xerox Phaser 3600 Service Manual

8-22 Phaser 3600 Printer Service Manual
Parts List
36 LEVER AUTO RELEASE L
37 TUBE SMALL
38 TUBE MIDDLE
39 RING E
40 THERMISTOR 130N01462
41 TUBE LARGE
42 SPRING ETC LOCK
43 LEVER AUTO RELEASE R
44 BUSHING-HEAT_ROLLER 013N13883
48 BEARING BALL
49 CAP FUSER LOCK
50 BUSHING PRESSURE_ROLLER 013N13884
52 HOLDER PR SHAFT
53 HEAT ROLLER 022N02351
54 BRACKET DRAWER
55 MEC-BRUSH ANTISTATIC
56 LAMP-DUAL 266 (110V)
LAMP-DUAL 266 (220V)
122N00277
122N00278
57 GROUND HR LAMP
58 SPRING CS
59 COVER FUSER LO LAMP
60 BRACKET LAMP-LEFT
61 CAP ACTUATOR
63 SPRING ETC GUIDE
64 FELT CLEAN TONER
65 GUIDE REAR LAMP
66 PRESSURE ROLLER 022N02352
PL 1.4 Fuser Assembly Parts List Table (continued)
Ite
m
No. Description Part Number

Xerox Phaser 3600 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	31 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Internal memory	32 MB
Maximum internal memory	512 MB
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Paper tray 2 input capacity	500 sheets
Functions	Print
I/O ports	Parallel (IEEE 1284), USB 2.0
Device manager	DHCP, Xerox CentreWare Internet Services Embedded Web Server, Xerox CentreWare Printer Management for Microsoft, Novell, and UNIX
Package length	563.87 mm
Depth (imperial)	18.8 \
Width (imperial)	15.7 \
Height (imperial)	15.1 \
Power requirements	240 V, 50/60 Hz
Standard input trays	2
Print memory (standard)	64 MB
Power consumption (active)	700 W
Compatible operating systems	HP-UX 10.2, Linux, Mac OS X ver.10.2 Red Hat 9, SCO, SUSE 9, Solaris 2.5.1/2.6+, Windows 2000/Vista
Acoustic power emissions (standby)	35 dB
Standard output capacity for envelopes	8000 sheets
Acoustic power emissions (active, print, copy or scan)	56 dB
PCL fonts	68
Certification	CE, UL 60950-1/CSA 60950-1-03, FCC Part 15 Class A, 73/23/EEC, RoHS 2002/95/EC
Maximum duty cycle	200000 pages per month
Recommended duty cycle	8000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	13 W
Power consumption (PowerSave)	130 W
Export Control Classification Number (ECCN)	EAR99

Weight and Dimensions

Depth	478 mm
Width	399 mm
Height	383 mm
Package width	515.61 mm
Package height	584.19 mm
Package weight	21201.2 g
Dimensions (WxDxH)	399 x 462 x 383 mm
