Xerox Phaser 6120

Parts Layout Drawing
Phaser® 6120 Color Laser Printer Service Manual
A-2
[1] Fusing Motor (M7) [6] Rack Motor (M2)
[2] Pressure/Retraction Solenoid /Cleaning
Blade (SL3)
[7] Registration Roller Solenoid (SL2)
[3] Main Motor (M1) [8] Tray1 Paper Pick-up Solenoid (SL1)
[4] Ventilation Fan Motor (M6) [9] Power Supply Cooling Fan Motor (M4)
[5] Developing Motor (M3) [10] Pressure/Retraction Solenoid /2nd Image
Transfer (SL4)
4139fs5502c0
[3]
[1]
[2]
[4]
[5]
[6]
[7]
[8]
[10]
[9]
