Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-23
Error Messages and Codes
PDL Error
Error relating to Printer Command Language (PCL) has occurred.
Applicable Chain Link
■ Chain Link 016-720: PDL Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
3 Check the memory card capacity. Print
the printer Configuration Page: Menu
> Information Pgs > Configuration.
Is the memory capacity correct,
including the optional memory?
Go to step 4. Replace the
Processor
Board
(page 8-60).
4 Replace the memory card. Does the
error still occur?
Replace the
Processor Board
(page 8-60).
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL8.1.9 “Map 3 - LVPS, Drive Motors, I/P Board, AC
Power” on page 10-10
“Controller” on page 10-31
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the print job.
1.Print a small print job (like a
Windows test print).
2.Does the error still occur?
Go to step 2. Complete.
2 Reseat plugs and jacks on the Image
Processor Board.
Does the error still occur?
Replace the
Processor Board
(page 8-60).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
