Xerox Phaser 6125 Service Manual

1-14 Phaser 6125/6130 Color Laser Printer Service Manual
General Information
Operating Mode
Mode Condition Description
Running Mode The printer is under operating condition
such as running or recording.
Fusing Maintained at operating temperature.
Exposure The Laser Unit Motor runs at the operating
speed.
Recording The system is operating.
Cooling Fan The fan operates at high speed.
Control Panel
Operation
LCD - Backlight: On
LED - Ready LED is turned On.
Ready Mode The printer is in standby status, ready to
run.
Fusing The system keeps the standby temperature.
Exposure The system is at Pause.
Recording The system is at Pause.
Cooling Fan The fan operates at low speed.
Control Panel
Operation
LCD - Backlight: On
LED: If printer is online, Ready LED is
turned On.
Power Saver
Mode (Deep
Sleep)
The printer enters into the Power Saver
mode to reduce power consumption when it
has not received print data for the specified
time.
Fusing The system is Off.
Exposure The system is at Pause.
Recording The system is at Pause.
Cooling Fan The system is Off.
Control Panel
Operation
LCD: Off, LCD Backlight: Off
LED: Power Saver LED is turned On.
Note: When the printer receives a print job or the Wake Up button is pressed, the
printer exits the Power Saver mode and enters the Ready mode.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
