Xerox Phaser 6125 Service Manual

A-6 Phaser 6130 Color Laser Printer Service Manual
Reference
Acronyms and Abbreviations
Acronym Description
A3 Paper size 297 millimeters (11.69 inches) x 420
millimeters (16.54 inches).
A4 Paper size 210 millimeters (8.27 inches) x 297
millimeters (11.69 inches).
A5 Paper size 148 millimeters (5.82 inches) x 210
millimeters (2.10 inches).
AC Alternating Current is type of current available at power
source for the printer.
ADC Automatic Density Control
AMPV Average Monthly Print Volume
APC Auto Power Control
ASSY Assembly
BCR Bias Charge Roller
BOOTP Boot Parameter Protocol
BTR Bias Transfer Roller
CAM Cam Shaft
CCD Charge Coupled Device (Photoelectric Converter)
CCW Counter-Clock Wise
CMYK Toner colors for the printer:
Y=yellow, C=cyan, M=magenta, K=black
CRU Customer Replaceable Unit
CRUM Customer Replaceable Unit Meter/Memory
CST Cassette
dB Decibel
DC Direct Current is type of power for printer components.
Machine converts AC power from power source to DC
power.
DDNS Dynamic Domain Name System
DDR2 DIMM Double Data Rate Dual In-Line Memory Module
DEV Developer
DHCP Dynamic Host Configuration Protocol
DPI Dot Per Inch
DRV Drive
DUP Duplex
Duplex 2-sided printing
EA Emulsion Aggregation (Toner)

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
