Phaser 6125/6130 Color Laser Printer Service Manual 3-53
Error Messages and Codes
Insert Imaging Unit
Initial Actions
■ Cycle printer power.
■ Ensure the Imaging Unit is installed correctly.
■ If problem persists, follow the procedure below.
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the life counter value of the
Transfer Belt: Service Mode >
Parameter > Life DTB Waste.
Is the life count value near the
maximum?
Replace the
Transfer Unit
(page 8-41).
Replace the
MCU Board
(page 8-59).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL8.2.13
■ Imaging Unit, PL4.1.21
■ “Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser” on
page 10-8
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Xerographic” on page 10-24
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the connectors between the
MCU Board and Imaging Unit.
Are P/J42 and P/J422 connected
securely?
Replace the
Imaging Unit
(page 8-8), then
go to step 3.
Securely
reconnect P/J42
and/or P/J422,
then go to step
2.
2 Does the error still occur when the
power is turned OFF and ON?
Go to step 3. Complete
3 Does the error still occur when the
power is turned OFF and ON?
Replace the
MCU Board
(page 8-59).
Complete

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
