Xerox Phaser 6125 Service Manual

4-44 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
Abnormal Noise and Electrical Problems
Abnormal Noise When Power is Turned On
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Imaging Unit (PL4.1.21)
■ Fuser (PL6.1.1)
■ Transfer Unit (PL6.1.7)
■
Sub Drive Assembly (PL7.1.1)
■ Main Drive Assembly (PL7.1.2)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Perform the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor Test
> Main Motor FULL2.
Is the noise still present?
Go to step 2. Go to step 5.
2 1. Reseat the Imaging Unit.
2.Perform the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Go to step 3. Complete
3 1. Reseat the connectors on the Transfer
Unit.
2.Perform the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Go to step 4. Complete
4 1. Reseat the Main Drive Assembly.
2.Perform the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Try replacing
one after
another:
■ Imaging
Unit
(page 8-8)
■ Transfer
Unit
(page 8-41)
■ Main Drive
Assembly
(page 8-52).
Complete
5 Perform the Sub Motor test (page 4-28):
Service Mode > Engine Diag > Motor Test
> Sub Motor FULL2.
Is the noise still present?
Go to step 6. Check the
installation
situation of
printer.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
